Stainless Steel Bellow Forming

Stainless Steel Bellow Forming machines are used to form convolutions on thin tubes made of stainless steel and other required metals. Hydraulic force is used to expand sectoral dies from inside the tubes. Expanding dies create convolutions from inside-out. Such convoluted tubes are used as expansion joints in piping network in industries. They are applied in automobiles at the exhaust point to avoid vibrations in the vehicles.

Get Quote
Get Quote
Key Features:
  • Powerful hydraulic cylinder.
  • Sectoral expansion dies
  • LM Guides for indexing slide.
  • PLC Controller
  • Indexing during convolution formation for smoothening the convolution
  • Stretch compensation by PLC
  • Single or multi-ply tubes for convolution
  • Ball screw and servomotor for slide used for indexing the convolution pitch.
Technical Specifictions
  • Material: Stainless Steel, Inconel, Hastealloy, Titanium.
  • Outside Diameter: 1100 mm
  • Thickness: 0,2 – 1 mm
  • No. of Plys: Upto 6-plys
  • Forming Force: By hydraulic cylinder
  • Stretching compensation: Provided
  • PLC: MITSUBISHI
Videos will be uploaded soon.
